For comfortable living
Column conditioning used to maintain optimum temperature in large rooms such as foyers of hotels, conference rooms, cafes and restaurants. Indoor unit does not require wall mounting, and installed directly on the floor.
Unlike other types of semi-conditioners, which can be concealed installation in suspended ceilings and air ducts, air conditioners in a column are increased requirements to the design of the indoor unit. Realizing this, EWT Clima has developed cutting-edge design of air conditioning in the style of Hi-Tech. Tower conditioner EWT Clima organically fit into any room and decorate the interior.
In Column conditioner control modes can be like using a touch panel located on the front of the mirror panel and by remote control. If desired, you can program the timer to activate or off the air conditioner.
Columns are equipped with air conditioning with automatic vertical blinds, which evenly distribute the air vertically, thus rapidly reaching the desired temperature in the room.
| Model | P-3YH | P-4YH | P-5YH | ||
|---|---|---|---|---|---|
| Cooling capacity | Btu / h | 32000 | 40000 | 50000 | |
| kW | 9.1 | 12 | 15 | ||
| Heat productivity | Btu / h | 36000 | 45000 | 55000 | |
| kW | 12.1 | 13.2 | 18 | ||
| EER/C.O.P. | W/W | 2,65/2,85 | 2,56/2,74 | 2,76/2,93 | |
| Supply voltage | A, V, Hz | 3, 380-415, 50 | 3, 380-415, 50 | 3, 380-415, 50 | |
| Power consumption | Cooling / Heating | W/W | 4800/4800 | 4800/4800 | 4630/4910 |
| Operating current | Cooling / Heating | A | 8,2/8,2 | 8,2/8,2 | 8,1/8,6 |
| Indoor unit | |||||
| Air Consumption | m3 / h | 1800 | 1800 | 1800 | |
| Noise level | dB (A) | 52 | 52 | 52 | |
| Dimensions | without packing | mm | 560x1910x360 | 560x1910x360 | 560x1910x360 |
| with packaging | mm | 2020x680x510 | 2020x680x510 | 2020x680x510 | |
| Weight | Net / Gross | kg | 58/72 | 58/72 | 58/72 |
| Outdoor Unit | |||||
| Noise level | dB (A) | 62 | 62 | 62 | |
| The diameters of pipelines | gas | mm (inch) | 15,88 (5/8) | 15,88 (5/8) | 15,88 (5/8) |
| fluid | mm (inch) | 9,52 (3/8) | 9,52 (3/8) | 9,52 (3/8) | |
| Dimensions | without packing | mm | 900x330x860 | 900x330x860 | 1255x340x945 |
| with packaging | mm | 1040x450x890 | 1040x450x890 | 1085x430x1300 | |
| Weight | Net / Gross | kg | 85/97 | 85/97 | 105/117 |
 |
Hot start |
 |
lock the keypad |
 |
Intelligent system for defrosting the outdoor unit |
 |
Removable washable filter |
 |
The engine of the outdoor unit with low noise |
 |
Quiet operation and maintenance tech |
